医疗麻醉导管挤出生产线
设备别名:精密医疗管挤出机 医疗管押出机 医疗管生产线 麻醉管挤出机 麻醉导管生产线 弹簧麻醉导管生产线 麻醉导管挤管机 加强型气管插管挤出机 医疗介入导管挤出机 X光显影导管挤出机生产线
一．医疗麻醉导管挤出生产线用途：
医疗麻醉导管挤出生产线主要用于生产普通型麻醉导管及弹簧麻醉导管以及加强型气管插管等各类精密医用级导管；
二．适用材料： 医用级PVC,PU
三.生产线构成:
精密挤出主机------高精度机头模具-------真空定型冷却水槽------医用牵引机----输送收集机----集成精密供气系统等
二．水槽冷却系统特点说明：
1、机械架构：
SUS304材质水槽,全钢化玻璃密封，水槽四周封板，适合医疗卫生无尘条件
2、三维调节系统：
前后采用导轨式调节,方便流畅，直线度好,上下调节采用四根丝杆调节,水槽更稳定,震动小
三、牵引部分
牵引系统：采用PU柔性多楔带,高精度直线导轨开合，长降调节机构，采用同步带传动方式，克服了采用齿轮传动进由于齿轮过齿时的轻微震动使牵引速度更平稳，为高品质制品提供保障
四、切断部分
切断与牵引采用了特殊结构,使切软质小管不易堵，切刀部分采用细软管专用无屑切断装置。
五、电气控制系统：
牵引机采用三菱伺服电机驱动，速度稳定精准，切断机采用三菱伺服电机驱动，日本三菱PLC，触摸式人机介面集成控制系统，计数精准，操作方便直观。实现了牵引，切断，输送三部份集中控制.
1. The extruders adopt Siemens man-machine interface and Siemens computer-control operation system, maintenance-free motor （Germany） and decelerator direct driving, which can effectively avoid low efficiency and big transmission error of general belt transmission. Dust, grease dirt and noise produced during manufacturing process are also avoided.
2. The cooling bath is made of imported SUS304 stainless steel with complete glass closed structure and stainless steel centrifugal pump for special medical-grade deionized water. Its water-annulus and low vacuum moulding ensures fine roundness and precision of pipes. Its air-annulus drying device allows the cooling water to be used circularly and not to splash the ground.
3. Biaxial diameter gauge adopts high velocity laser light source, Japan TOSHIBA high-precision CCD, digital image manipulation, non-contacting measuring for online products and real-time digital display with measuring precision of ±0.003mm.
4. The haul-off unit consists of belts made from Switzerland, servo motor and controller of Japan MITSUBISHI, turbine and worm decelerator from Germany. It can work with high precision and stability and no skidding or noise.
5. The cutting unit is equipped with aluminum alloy rotatable Knife arm of low-inertia as well as special cutting Knife pouch which ensures smooth cuts. It’s servo motor driving and PLC programming controlling of Japan MITSUBISHI, as well as Siemens man-machine interface ensure precision of cutting length. Cutting length can be set at will and cutting times can be counted automatically.
6. The extruder and the haul-off adopt complete closed loop servo motor which enables hauling speed to change with the extruder speed, and consequently ensure speed synchronization on the whole line with high precision and frequency responsibility. It can also prevent pipe diameter from fluctuating when working speed is changed due to environmental factors, and thus ensures product precision up to ±0.03.
